ISO 13953 specifies the procedure for evaluation of the tensile strength and failure characteristics of butt-fused joints in polyethylene (PE) pipes. This procedure helps determine the quality of fusion welding by applying a controlled tensile force to test specimens cut from a fused pipe joint.
ISO 13953:2001 is an internationally recognized standard that outlines a testing method for determining the tensile strength and failure mode of test specimens cut from butt-fused joints in polyethylene (PE) pipes and fittings. This standard is specifically applicable to PE pipe assemblies with a nominal outside diameter of 90 mm or greater. It provides a clear and reliable procedure for assessing the mechanical performance and structural integrity of butt-fused joints under tensile stress. ISO 13953:2001 plays a crucial role in quality control and assurance processes by identifying potential weaknesses in fusion-welded joints, helping manufacturers, engineers, and quality testing labs ensure long-term reliability and safety of PE piping systems. Often used alongside other test methods, it serves as a valuable tool for evaluating fusion joint quality in applications across water distribution, gas pipelines, and industrial piping networks.
ISO 13953:2001 describes a method for testing the tensile strength and failure mode of specimens cut from butt-fused joints in polyethylene (PE) pipes and fittings. The process begins by preparing a properly fused joint using standard procedures. A specimen is then cut lengthwise from the joint, ensuring the weld is centered. The sample, typically 20 mm wide, is conditioned at 23°C and 50% humidity for at least 24 hours before testing.
The specimen is mounted in a tensile testing machine, aligned axially, and pulled at a constant speed of 5 mm/min until failure. The maximum force is recorded, and the failure mode is examined to determine whether the break occurred within or outside the fusion zone. Ductile failure indicates a good weld, while brittle or interfacial failure may suggest poor joint quality. A test report documents the results, including specimen details, test conditions, maximum load, and failure type.
